Whirlwind MT-8-F-S-10 - Snake - Fan to Fan, 8 XLRF to 8 TRSM, 10', W09PR

Write a Review

Ask a Question

Whirlwind MT-8-F-S-10 - Multitrack, 8 Channels, Xlrf-Trs 10' 692465008976.

MEDUSA Multitrack Audio Snake

8 channels, WI3F (XLR female) connector End A,1/4" TRS connector End B and 10 feet

The Medusa Multitrack (MT) Series is designed to interface multitrack recorders or outboard equipment to mixing consoles.

Available in "Whirlwind Blue" multipair cable or Black upon request.

Each Multitrack Medusa is constructed of Whirlwind multipair cable with a heat-shrunk fanout at each end, and is available with optional Snakeskin for an extra charge. An alternative construction uses individually jacketed (IJ) Canare wire with Snakeskinfanouts standard.

Choose from 4, 6, 8, 12, 16, 24 or 32 line configurations (other channel counts available special order) and Whirlwind XLRs, RCA Phono plugs or 1/4" TRS plugs.

Each fanout can be specified with distinct connector types and signal polarity. When the same type of connector is specified at each end, wiring is pin to pin. Wire mesh hanger grips can be ordered as an option.

Ordering information:

Catalog Number:

MT 1 2 3 4 5 6

Example - MT32FM25SSH

Number of Channels 1

Option

4 - 4 channels

6 - 6 channels

8 - 8 channels

12 - 12 channels

16 - 16 channels

20 - 20 channels

24 - 24 channels

32 - 32 channels

Type of Connectors End A 2

Option

F - WI3F (XLR female)

M - WI3M (XLR male)

S - 1/4" TRS

TT - TT patch plugs

LF - long frame patch plugs

R - RCA plugs

Type of Connectors End B 3

(Use table #2)

Cable Length in Feet (M) 4

Option

10 - 10' (3.05m)

25 - 25' (7.62m)

50 - 50' (15.25m)

XX - custom length

Snakeskin Option 5

Option

SS - Snakeskin on fanout (extra charge)

(Blank) - no snakeskin

Hanger Option 6

Option

H - hanger grips at each end

(Blank) - no hanger grips

Standard Snakeskin^® Colors

Input Ch #	Std Color
1-8	black
9-16	white
17-24	blue
25-32	purple
33-40	yellow
41-48	green
49-56	orange
All Returns	red
