Bud Industries NBE-10563, L11 X W7 X D6, NEMA 4X Box IP67

Bud Industries NBE-10563, L11 X W7 X D6, NEMA 4X Box IP67
Click To Enlarge
MSRP: $146.52
Sale Price: $73.26
You Save $73.26 (50%)
USD
Qty:

$50 Minimum Order

Normally in stock. Please contact us to confirm
Image may vary. Please contact us if you need more images, quote or other information.

• Brand: Bud Industries

• MPN: NBE-10563

• Ship Weight: 5.78lbs

• Condition: New

• Availability: In Stock

• Seller: A-I Consolidated

• Keywords: NBE-10563, Bud Industries, L11 X W7 X D6, NEMA 4X Box UL/NEMA/IEC IP67,

• Category: Electronics > Electronics Accessories

Bud Industries NBE-10563 - NEMA 4X Enclosures-NBE series-UL/NEMA/IEC IP67-L11 X W7 D6 Non-Metal Bx-Style E-Clear Dr.




NEMA Box with Aluminum Swing-Out Panel NBE-10563

  • Designed to IP66 of IEC 529 and NEMA 1, 4 and 4x specifications.
  • UL Listed to UL508-4x requirements
  • ABS/PC blended plastic enclosures are molded out of light gray material with UL94-5VA flammability rating. Suggested service temperature range -40C to +70C.
  • Clear doors are molded out of polycarbonate material with UL94-V0 flammability rating
External Size L x W x D: 11.28" x 7.48" x 5.52"
Internal Size L x W x D: 10.46" x 6.65" x 5.25"
Weight: 3.5 lbs
Color: Light Gray
RoHS Certified: Always Compliant
Indoor / Outdoor: Indoor (Not UV Stabilized)
Flammability Rating: UL94-5VA
Door Flammability Rating: UL94-V0
Type of Plastic: ABS
Door Type of Plastic: Clear Polycarbonate
UL Rating: UL508
Service Temperature Min: -40°C
Service Temperature Max: 70°C
NEMA Rating: NEMA 1, NEMA 4, NEMA 4X
IP Rating: 66
Cover Style: Clear, Hinged Cover
